INKBIRD WiFi 6” Inline Duct Fan with Temperature Humidity Intelligent Controller

The duct fan has a large air volume, low noise, and fast speed and has the functions of ventilation, deodorization, and temperature regulation. With a Wi-Fi-enabled smart controller with automatic, manual, and timer modes, creating a comfortable living environment for our family, plants, and pets.

Description

Notes:

1. During installation, please ensure that all accessories are installed properly and that the fan structure can withstand the load generated by the fan running at full load.

2. Before use, please ensure that the power supply is disconnected even if this product is powered off.

3. Before plugging in power, please ensure that the voltage and frequency of the main power supply match the data on the product nameplate.

4. Do NOT remove the iron clips on the fan blades as they balance the fan.

5. This product is not suitable for children or frail people, unless supervised by a responsible person to ensure that they can use this product safely.

6. Before use, be sure to remove the equipment residue that may have been sucked into the fan, and clean up the ducts.

INKBIRD IVC - 001W has the functions of ventilation, deodorization, dehumidification, and temperature regulation. With its Wi-Fi capability, we can remotely control duct fans anytime, anywhere to create a comfortable living environment for our family, plants, and pets.

Main Features

Inline duct fan with temperature and humidity controller for grow tents, vertical farms, etc.
Wi-Fi enabled smart controller, remotely monitor via smartphone anytime, anywhere
Automatic mode/Manual mode/Timer mode, 3 control modes to run the fan
Comes with a premium probe to detect temperature and humidity simultaneously
350CFM air flow with variable fan speed, strong performance on air ventilation
32dB-A quiet operation, hardly any noise to disturb you in daily life
Adopts energy-efficient EC motor, plug-and-play, power-saving and cost-saving
Supports temperature alarms, humidity alarms, and calibration function
Child-lock function to prevent misuse by children, safer in use

Child Lock/ECO Mode on Smart Controller & INKBIRD APP

High Quality for Long-time Use, ABS shell, Strong fan blades, EC motors

Know Your 6-inch Wifi Duct Fan How to Work

Inline duct fan function: increases airflow and heat dissipation, achieves:

Maintain an odor-free environment;
Maintain adequate airflow in all areas.

Not only has basic temperature and humidity triggers, but also guides the air through your target location, in the 0~10 level wind speed adjustment range, the relationship between air volume/wind speed/noise decibel changes perfectly meets your indoor/growth needs.

Specifications

● Product Name: Inline Duct Fan with Smart Controller

● Model: IVC-001W

● Duct Fan Power: 110~240Vac 50/60Hz

● Smart Controller Power: DC24V

● Duct Size: 6 inches

● Airflow: 350CFM

● Fan Speed: 2500 RPM

● Noise: 32dB-A

● Temperature Display Accuracy: 0.1℃/℉(<100℃/℉),1℃/℉(>=100℃/℉)

● Humidity Display Accuracy: 0.1%RH

● Relative Humidity Detection Range: 0~100%RH

● Relative Humidity Detection Accuracy (at 25℃): typical value ±2%RH

● Temperature Detection Range: -40℃~100℃/-40℉~212℉

● Temperature Detection Accuracy: typical value ±0.3℃/±0.5℉

● Working Temperature: Room Temperature

● Storage Condition:

Temperature：0℃~60℃/32℉~140℉

Humidity：20~80%RH (Unfroze or condensation state)

● Product Warranty: 2 Years

● AC Cable Length: 1.5 m

● DC Cable Length: 2.4 m

● Probe Cable Length: 2500 ±30 mm

Package Contents

Duct Fan Unit

1x Inline Duct Fan

2x Duct Clamp

6x Wire Tie

6x Wire Tie Mount

6x Wood Screws

6x Wood Screws (Wall Hang)

Controller Unit

1x Smart Controller

1x Temperature-Humidity Probe

2x Machine Screws (Wall Mount)

2x Wood Screws (Wall Mount)

2x Wood Screws (Wall Hang)
